Overview
The E51.716/16 Button Thermostat is a programmable room controller operated entirely by physical buttons on the panel — no touch screen to scratch, no app to learn. Designed for electric heating and carbon film systems, it holds each room at its setpoint and keeps hotels, hospitals, schools and offices warm, zone by zone. It is the dependable, low-fuss member of our thermostats & controls range.
Install it with electric heating mats or carbon/graphene heating film. When remote control is required, step up to the WiFi siblings — the Y603H WiFi thermostat or Y819H WiFi thermostat; for touch operation see the E91.716 touch thermostat.
Key Features
- Physical button operation — raised keys give clear tactile feedback; usable with wet or gloved hands.
- Programmable — scheduled temperature periods through the week without a smartphone.
- Electric & carbon film heating — purpose-built for electric underfloor and carbon film systems.
- Public-building proven — widely used in hotels, hospitals, schools and office buildings.
- Simple mode selection — set temperature, choose mode, done.
- 3 m NTC floor sensor — protects sensitive floor finishes.
- Flame-retardant PC + ABS body — durable for high-traffic corridors.
- No network dependency — works offline forever; no WiFi to pair or forget.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | E51.716/16 |
| Type | Programmable button-type room thermostat |
| Heating systems | Electric underfloor heating; carbon film heating systems |
| Typical load | 16 A electric heating (confirm per project) |
| Control | Direct buttons; on-device programming |
| Sensor | Room sensor + 3 m external NTC floor sensor |
| Display | LCD temperature / programme readout |
| Body material | Anti-flammable PC + ABS |
| Typical projects | Hotels, hospitals, schools, office buildings |
| Warranty | 2 years; online technical support, free spare parts, return & replacement |
| Certification | CE, RoHS |
Wiring & Installation
Mount on a standard recessed wall back box. Mains L/N feed the unit; the load output switches the electric heating or carbon film circuit. Lay the 3 m NTC floor sensor beneath the floor finish between two element runs, and route it into the sensor terminals. Where the circuit exceeds the rated load, switch a contactor from the thermostat output. Commission the programmed schedule after installation, and protect the circuit with RCD devices per local wiring rules.
Compatible Heating Systems
- Electric heating mats — direct switching under tile and stone.
- Carbon / graphene heating film — suspended floors and renovations.
- Heating cables — looped wet-area circuits.
- Underfloor heating mat — residential and commercial rooms.
- Underfloor heating systems category — zoning design.
Programming & Operating Modes
Buttons step through the menu: set target temperature, select mode (comfort / setback / anti-freeze), and programme weekday and weekend time periods. Once programmed, the unit runs unattended — holding comfort during occupied hours, dropping to setback overnight. The child/guest lock prevents tampering in public rooms. Because everything is on-device, maintenance staff never depend on a network or app account to adjust a room.
Safety & Certifications
Flame-retardant PC+ABS enclosure, 100 % factory testing, CE and RoHS certification under ISO 9001 quality management. The floor sensor caps floor temperature for wood and carpet finishes; guest lock keeps public rooms on schedule; freeze protection holds a safe minimum when buildings are unoccupied. RCD-protected circuits complete the installation safety standard.
Factory & Quality
SunAura Thermal has manufactured heating controls and elements in Qingdao since 2008, exporting to more than 50 countries. The E51.716/16 is SMT-assembled and burn-in tested on our own lines, backed by a 2-year warranty with online technical support, free spare parts and return/replacement service. The full control family is listed in the thermostats & controls category.
Packaging & Shipping
Each unit ships boxed with the 3 m sensor, fixing kit and multilingual quick-start guide. Cartons are pallet-optimised for sea freight, with express courier for urgent replacements. CE/RoHS certificates and batch test records travel with the shipment; multilingual manuals and private-label boxes are available for distributors.
OEM / ODM
Private label covers fascia silkscreen, custom packaging and multilingual manuals. ODM work on button layout, schedule presets (hotel / school / office profiles) and bundled controller-plus-heating-kits runs in-house. Samples are available before a bulk order, with flexible MOQ for first-time distributors.
Wholesale Pricing & How to Buy
Factory-direct pricing is tiered by quantity for distributors, contractors and project buyers; sample units are offered first. Tell us the heating system, voltage and room count, and we will confirm the configuration and return a same-day quotation. Contact our sales team for factory price, wholesale terms and free-sample arrangements.
FAQ
Is this thermostat WiFi or app controlled?
No — the E51.716/16 is a button-operated, on-device programmable thermostat. If you need remote app control, choose our Y603H or Y819H WiFi thermostats, which share the same electric-heating and carbon-film application.
Why choose buttons over a touch screen in public buildings?
Raised keys work with wet or gloved hands, resist scratches and vandal smudges, and need no cleaning protocol — which is why button models are common in hotels, hospitals and schools.
Which heating systems does it control?
It is built for electric underfloor heating systems and carbon film heating systems: setting temperature, selecting mode and running scheduled periods across rooms.
Can guests change the temperature freely?
A guest lock holds the programmed schedule, useful for hotels and schools; operators can also allow limited local adjustment within set limits. We can pre-configure these at your request.
What warranty is included?
2 years, with online technical support, free spare parts and return/replacement service — extended cover available on project contracts.
Related Products
More room controllers in the same range:
- E91.716 touch thermostat — touch-screen sibling, same system family
- Y308 knob thermostat — simple knob control alternative
- K6H thermostat — established SunAura control model
Back to the thermostats & controls collection, or request a wholesale quote for the E51.716 button thermostat.
