Overview
The E91.716/16 Touch Thermostat is a programmable room controller operated by a glass touch screen: set the temperature, choose modes and run the weekly schedule with a finger. Built for electric heating and carbon film systems, it brings a modern, easy-clean fascia to homes, hotels, hospitals, schools and offices. It is part of our thermostats & controls range.
Pair it with electric heating mats and carbon/graphene heating film. Need app remote control? See the HY312 WiFi touch thermostat; prefer physical keys? Compare the E51.716 button thermostat.
Key Features
- Touch screen operation — glass panel with clear on-screen keys; wipes clean in kitchens and bathrooms.
- Programmable — weekly schedule with comfort and setback periods, set on-panel.
- Electric & carbon film heating — purpose-built for electric underfloor and carbon film systems.
- Mode selection — touch to set temperature, pick heat / setback / anti-freeze modes.
- Public-building proven — hotels, hospitals, schools and offices.
- 3 m NTC floor sensor — protects wood, laminate and carpet finishes.
- Flame-retardant PC + ABS body — slim modern flush-mount fascia.
- Child / guest lock — holds programmed settings in shared rooms.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | E91.716/16 |
| Type | Programmable touch screen room thermostat |
| Heating systems | Electric underfloor heating; carbon film heating systems |
| Typical load | 16 A electric heating (confirm per project) |
| Control | Direct touch screen; on-device programming |
| Sensor | Room sensor + 3 m external NTC floor sensor |
| Display | Backlit touch screen |
| Body material | Anti-flammable PC + ABS |
| Typical projects | Hotels, hospitals, schools, office buildings |
| Warranty | 2 years; online technical support, free spare parts, return & replacement |
| Certification | CE, RoHS |
Wiring & Installation
Mount on a standard recessed wall back box. Feed mains to L/N terminals; the load output switches the electric heating or carbon film circuit. Lay the 3 m NTC floor sensor beneath the floor finish between two element runs and connect it to the sensor input. For circuits above the rated load, drive a contactor from the output. Once powered, the touch menu lets you select sensing mode (air / floor / floor-limited) and set the weekly programme. RCD-protected installation by a qualified electrician.
Compatible Heating Systems
- Electric heating mats — direct switching under tile and stone.
- Carbon / graphene heating film — suspended and renovated floors.
- Heating cables — looped wet-room and whole-floor zones.
- Bathroom floor heating mat — wet-room floor-limited control.
- Underfloor heating systems — zoning design.
Programming & Operating Modes
The touch menu steps through setpoint, mode and schedule: comfort temperature for occupied hours, setback overnight or away, anti-freeze minimum for vacant periods. Guest lock freezes the programme in public rooms; calibration offset and floor-temperature limits are set on-screen. Because programming is on-panel, it works on day one with no app account, network pairing or manual lookup required.
Safety & Certifications
Flame-retardant PC+ABS enclosure, 100 % factory testing, CE and RoHS certification under ISO 9001-managed production. The floor sensor enforces a safe floor-temperature ceiling for wood and laminate; guest lock prevents tampering; freeze protection guards empty rooms through winter. RCD-protected circuits complete the installation standard.
Factory & Quality
SunAura Thermal has manufactured heating controls and elements in Qingdao since 2008, exporting to more than 50 countries. The E91.716/16 is SMT-assembled and burn-in tested on our own lines, with a 2-year warranty including online technical support, free spare parts and return/replacement. The complete control line is listed in the thermostats & controls category.
Packaging & Shipping
Units ship boxed with the 3 m sensor, fixing kit and multilingual quick-start guide; cartons are pallet-optimised for sea freight, with express courier for urgent projects. CE/RoHS certificates and batch test records accompany the shipment; multilingual manuals and private-label boxes are available for distributor programmes.
OEM / ODM
Private label covers fascia silkscreen, custom packaging and multilingual manuals. ODM work — touch UI presets, branded splash screens, or bundled controller-plus-heating kits — is handled in-house from prototype to production. Samples are available before a bulk order, with flexible MOQ for first-time distributors.
Wholesale Pricing & How to Buy
Factory-direct pricing is tiered by quantity; sample units are offered first. Tell us the heating system, voltage and room count, and we will confirm the configuration and return a same-day quotation. Contact our sales team for factory price, wholesale terms and free-sample arrangements.
FAQ
Is this touch thermostat WiFi controlled?
This E91.716/16 model operates on-panel with touch keys and on-device scheduling. Choose our HY312 WiFi touch thermostat when you need app remote control alongside the touch interface.
Which heating systems does it control?
It is built for electric underfloor heating and carbon film heating systems: set temperature, choose modes and run weekly schedules room by room.
Can it protect laminate and wood floors?
Yes — in floor-limited mode the 3 m NTC sensor caps the floor temperature at the finish manufacturer’s safe maximum, which is essential under wood and carpet.
Is the touch panel usable in hotels?
Yes — it is widely used in hotels, hospitals, schools and offices. Guest lock holds the schedule while the touch face stays clean and modern in public areas.
What warranty is included?
2 years, with online technical support, free spare parts and return/replacement service; extended project cover is available.
Related Products
More room controllers in the same range:
- HY312 WiFi touch thermostat — add app remote control
- E51.716 button thermostat — physical-key sibling
- Touch WiFi thermostat range — our established touch line
Back to the thermostats & controls collection, or request a wholesale quote for the E91.716 touch thermostat.
